Description
Technical features
| Number of Ways | 4 |
| Low Way (Mono) | Frequency cut / Variable (LPF): 40Hz ~ 275Hz(-12dB/8th) |
| Low Mid Way (Mono) | Minimum Frequency of HPF cut / Variable: 25Hz ~ 140Hz(-12dB/8th) Maximum Frequency of LPF cut / Variable: 300HZ ~ 7.5Hz (-12dB/8th) |
| High Mid Way (Stereo) | Minimum frequency of HPF cut / Variable: 200Hz ~5KHz (-12dB/8th) Maximum frequency of LPF cut / Variable: 1.2KHz ~ 12KHz(-12dB/8th) |
| High Way (Stereo) | Frequency cut / Variable: 550Hz ~13.7KHz (-12dB/8th) |
| Output Impedance | 27k ohms |
| Maximum Input Level | 8V RMS |
| Maximum Output Level | 8V RMS |
| Protection System | Against polarity reversal |
| Power Supply Voltage | 10 ~ 15.5VDC |
| Dimensions(H X W X D) | 7.48" x 1.57" x 5.70" |
| Weight | 1.234lb |
