Description
Technical features
| Output Voltage | 90 ~ 302VDC - 7 ~ 24 Batteries |
| Rated power | Maximum power @ 164VDC- 0.5 Ohm: 20,000W RMS |
| Rated power | Maximum power @ 227VDC- 0.5 Ohm: 40,000W RMS |
| Input Sensitivity | 310mV (Gain 100%) @ 1 Ohm |
| Aux Input standard | 0.3% |
| Signal to Noise Ratio | >95dB |
| Frequency response | 10Hz ~ 8KHz (-1dB) |
| Protection system | Output short circuit, output short circuit to GND, low voltage, high voltage, and thermal protection |
| Power Supply Voltage | 10VDC Maximum supply voltage: 340VDC |
| Consumption at rest | 52mA |
| Maximum Musical Consumption | Maximum musical consumption @ 0.5 Ohm: 67A (20,000W RMS) / 91,5A (40,000W RMS) |
| Maximum Musical Consumption | Maximum sinusoidal consumpt. @ 0.5 Ohm (60Hz): 134A (20,000W RMS) / 183A (40,000W RMS) |
